Module

To lower the development threshold for users, Chipintelli has developed matching voice modules based on AI voice chips, providing integrated hardware and software solutions. Users can flexibly select the appropriate voice modules according to their product structure and positioning, enabling easy integration of voice functionality into their products.

Product Select

Selection of chips, modules, and EVK products for the entire series

View
AI-SDK

complete and open-source SDK for easy secondary development

View

CI13XX Series

Hardware Design Reference

Cost-effective Natural Speech Recognition

• CI13XX Series modules are available in various forms, including terminal interfaces, SMT mounting, gold finger, and USB interfaces, with an operating voltage of 3.6V-5.5V. They feature an onboard power amplifier and one or two microphone channels.

• Powered by Chipintelli BNPU V3, supporting DNN\TDNN\RNN\CNN neural networks and parallel vector operations, these modules enable voice recognition, voiceprint recognition, command word self-learning, AI sound event detection, offline TTS, and deep learning noise reduction.

• They use industrial-grade components for high reliability.

Module Model	Compatible Chip	Interface Type	Mics	UARTs	AEC Support	PCB Layers	Dimensions (mm)	Module Status	EVK
CI-D02GS01J	CI1302	Terminal	1	1	Yes	2	40×30	Mass Production	CI1301&CI1302&CI1303 EVK
CI-D03GS01J	CI1303	Terminal	1	1	Yes	2	40×30	Mass Production	CI1301&CI1302&CI1303 EVK
CI-D02GS02S	CI1302	SMT	1	3	Yes	2	18×20	Mass Production	CI1301&CI1302&CI1303 EVK
CI-D03GS02S	CI1303	SMT	1	3	Yes	2	18×20	Mass Production	CI1301&CI1302&CI1303 EVK
CI-D02GS04U	CI1302	USB	1	1	Yes	2	26×35	Mass Production	CI1301&CI1302&CI1303 EVK
CI-D06GT01J	CI1306	Terminal	2	1	Yes	2	40×30	Mass Production	CI-D06GT01J EVK
CI-D12GS10T	CI1312	Gold Finger	1	1	Yes	2	20.5×13.8	Mass Production	CI-D12GS08J EVK
CI-D12GS08J	CI1312	Terminal	1	1	Yes	2	40×30	Mass Production	CI-D12GS08J EVK

CI13LC Series

Hardware Design Reference

Cost-effective Command Word Recognition

• CI13LC Series modules come in various forms, including terminal interfaces, SMT mounting, and gold finger contacts, with an operating voltage of 3.6V-5.5V. They feature an onboard power amplifier, one microphone channel, one speaker channel, one 5V power supply, and a UART interface.

• Powered by Chipintelli BNPU V3.5, supporting DNN\TDNN\RNN\CNN neural networks and parallel vector operations, these modules enable offline voice recognition, single-microphone noise reduction and enhancement, multi-intent recognition, and support for up to 300 local voice entries.

• They use industrial-grade components for high reliability.

Module Model	Compatible Chip	Interface Type	Mics	UARTs	AEC Support	PCB Layers	Dimensions (mm)	Module Status	EVK
CI-F08XGS02J	CI13082V	Terminal	1	1	No	2	40×30	Mass Production	CI-F08XGS02J EVK
CI-F162GS02J	CI13162	Terminal	1	1	No	1	40×30	Mass Production	CI-F162GS02J EVK
CI-F162GS02T	CI13162	Gold Finger	1	1	No	2	20.5×13.8	Mass Production	CI-F162GS02J EVK
CI-H162GS01J	CI13162P	Terminal	1	1	No	1	40×30	Mass Production	CI-H162GS01J EVK
CI-F242GS01J	CI13242	Terminal	1	1	No	2	40×30	Mass Production	CI-F242GS01J EVK
CI-F242GS01S	CI13242	SMT	1	3	No	2	18×20	Mass Production	CI-F32XGT01D EVK
CI-F322GS01S	CI13322	SMT	1	3	No	2	16×11	Mass Production	CI13322 EVK

CI230X Series

Hardware Design Reference

High-performance AIoT Combo

• Smart Voice AIoT Module.

• The module's main chip integrates Chipintelli BNPU V3 along with Wi-Fi and BLE Combo functionality.

• The system can reach a main frequency of 220MHz, with built-in large-capacity SRAM, integrated PMU power management unit, dual-channel high-performance low-power Audio Codec, and multiple peripheral control interfaces including UART, I2C, I2S, PWM, and GPIO. It also integrates PA/LNA/TRX Switch on-chip.

Module Model	Compatible Chip	Interface Type	Mics	UARTs	AEC Support	PCB Layers	Dimensions (mm)	Module Status	EVK
CI-E05GT02S	CI2305	SMT	2	2	Yes	4	16×24	Mass Production	CI230X EVK
CI-E06GT02S	CI2306	SMT	2	2	Yes	4	16×24	Mass Production	CI230X EVK
CI-E05GT03S	CI2305	SMT	2	2	Yes	4	18×25.5	Mass Production	CI230X（LCD）EVK
CI-E06GT03S	CI2306	SMT	2	2	Yes	4	18×25.5	Mass Production	CI230X（LCD）EVK

CI23LC Series

Hardware Design Reference

Cost-effective Voice recognition & BLE Combo

• CI23LC Series modules feature terminal interfaces and gold finger contacts, with an operating voltage of 3.6V-5.5V. They include an onboard power amplifier and one microphone channel.

• Powered by Chipintelli BNPU V3.5, supporting DNN\TDNN\RNN\CNN neural networks and parallel vector operations, these modules deliver high-performance offline voice recognition and voice noise reduction, with strong environmental noise suppression capabilities.

• They integrate high-performance, low-power Bluetooth BLE and support mini-program control.

Module Model	Compatible Chip	Interface Type	Mics	UARTs	AEC Support	PCB Layers	Dimensions (mm)	Module Status	EVK
CI-G162GS02J	CI23162	Terminal	1	1	No	2	40×30	Mass Production	CI-G162GS02J EVK
CI-G162GS02T	CI23162	Gold Finger	1	1	No	2	22.1×16.2	Mass Production	CI-G162GS02J EVK
CI-G162GS03T	CI23162	Gold Finger	1	1	No	2	20.5×19	Mass Production	CI-G161GS02J EVK
CI-G242GS02J	CI23242	Terminal	1	1	No	2	40×30	Mass Production	CI-G24XGS02J EVK
